Description
sheet metal CNC Hybrid Press Brake Front Sheet CNC Followers automatic front support
Description
▪ Save labor
▪ Suitable for all kinds of large plate bending work, especially thin and large plates, which reduces the workload of operators to move heavy objects, improves bending efficiency, and reduces operator risks.
▪ Independent system module control, perfectly synchronized with the Y axis during the bending process.
▪ Automatically adjust the up and down movement according to the height of the mold and the size of the V port.
▪ Equipped with parking space to avoid the impact on the workpiece when reverse bending.
▪ Flexible and easy to use, easy to install and unload, can be moved from one device and installed on another device.
▪ Equipped with a brush station to prevent any plates from scratching, sliding or falling.
▪ Suitable for matching with various brands and models of bending machines.
▪ Independent control system, no need to modify the bending machine.
Main configuration
| Name | Producer |
| CNC controller | DA69T Delem Holland brand |
| Main motor | Siemens Germany brand |
| Electrical components | Schneider France brand |
| Gear pump | Sunny USA brand |
| Seal ring | NOK Japan brand |
| Hydraulic system | Boschrexroth Germany brand |
| Ball screw ,Linear guide | HIWIN Taiwan brand |
| Grating ruler | GIVI Italy brand |
| Tubing connector | EMB Germany Brand |
| Back guage servo motor and drive | Delta Taiwan Brand |
The standard accessories are in the below:
- Anchor bolt 2. Hex nut 3. Seal ring 4. Gasket 5. Grease gun 6. Allen wrench 7. Foot switch 8. Front support arms 9. Electrical box key, control panel key 10. Operation manuals
