Eight usage specifications and maintenance methods of CNC metal pipe benders machine
CNC metal pipe bending machine is a new type of pipe bending tool with pipe bending function and top function. It has many advantages such as reasonable structure, safe use, convenient operation, reasonable price, fast loading and unloading, easy to carry, and one machine for multiple purposes. Installation of plumbing and repairs in buildings, railways, automobiles, etc. In addition to the pipe bending function, it can also be used as a separate hydraulic jacking machine by removing the pipe bending parts.
Then the CNC metal pipe bending machine purchased back should pay attention to the following points when using it:
- Before operation, please check whether the lubricating points of the machine are short of oil, whether the safety protection device is reliable, and whether the moving mechanism is loose, and then start the operation after one confirmation.
- Start the CNC metal elbow oil pump and check whether the system pressure is kept within the specified range. If it is high, it will damage the hydraulic components and waste power. If it is too low, it will affect the work.
- Adjust the required position and required angle of the parts, and position the parts to the required length.
- Adjust the vertical lift guide so that the guide die pressing cylinder can move forward and tighten the iron pipe.
- Enable the clamping cylinder to clamp the iron pipe.
- In normal operation, put the workpiece into the bending die, and the front end is in contact with the positioning, step on the foot switch, and it can be completed.
- After the work is over, cut off the power supply and do a good job of cleaning and lubrication.
- In case of emergency when operating the CNC metal pipe bending machine, press the emergency stop button, then turn the rotary switch to the manual position, and reset it manually. If a fault occurs, please report for repair in time.
Let’s talk about eight methods for the maintenance of CNC metal pipe bending machine:
One: When operating the CNC metal pipe bending machine, it must be operated in strict accordance with the operating regulations (key).
Two: The CNC metal pipe bending machine must be kept clean, and the unpainted part should be coated with anti-rust grease.
3: Add lubricating oil regularly, fixed-point and quantitatively according to the requirements of the lubrication chart before each CNC metal pipe bending machine is started. The oil should be clean and free of precipitation.
Four: Regularly check and repair the switch, insurance, handle, and ensure its reliable operation.
Five: The lubricating oil in the motor bearing should be replaced and filled regularly, and the motor part should be checked regularly to see if it is working properly.
Six: Regularly check whether the V-belt, handle, knob, and button are damaged. If the wear is serious, it should be replaced in time.
Seven: It is strictly forbidden for non-designated personnel to operate the equipment. Usually, people must leave the machine and stop.
Eight: 10 minutes before get off work every day, lubricate and clean the CNC metal pipe bender.
The last station and experts said that in addition to the function of bending, the CNC metal pipe bending machine can also remove the oil cylinder in the bending part and use it as a separate hydraulic jacking machine. Generally, it has good anti-emulsification performance and good anti-foaming performance. Oil with good lubricating properties.
Primapress pipe bending machine department manufactured CNC metal pipe benders, CNC CNC metal pipe benders, hydraulic CNC metal pipe benders, automatic CNC metal pipe benders and other equipment. The company abides by: “Quality First, Customer First, Integrity-based” business philosophy, sincerely welcome new and old customers to visit and patronize, all staff will wholeheartedly provide you with a full range of services.
